Free download manual fiber trace unicode jdsu Files at Software Informer. Fiber Trace Viewer is very useful and easy-to-use software package especially designed for. Software Downloads and Updates. Software (Complete Software. Looking for our Optical Security and Perfomance Products website? Visit our OSP website.

Price: Condition Refurbished / Calibrated Warranty 90 Day Exchange Included. Acterna MTS 5100eo Color Mainframe (BC# 16937). Acterna 5026VSR Singlemode OTDR Module. SM OTDR Source:. 1310nm. 1550nm.

Interchangeable SC Connector For Source. (2) SM SC-SC Fiber Cables. (4) Fiber Optic Wipes. AC Adapter/Charger. Power Cord.

Fiber Trace Software

RS232 PC Interface Cable. User Manual On CD-ROM.

Carrying Case w/ Strap The Acterna (MTSe) OTDR is the fastest, most reliable and accurate OTDR currently on the market. Taken together, the module’s automation and rapid testing features offer impressive time savings for companies involved in commissioning and locating faults in optical fiber networks. MAXIMIZING FIELD PRODUCTIVITY: The most important prerequisites for testing in the field are ease-of-use and speed of acquisition. The OTDR module ensures maximum test productivity by providing one-button, automated operation for all of its critical test routines and a very high data acquisition speed of 40 dB in seconds.

DELIVERING THE INDUSTRY'S HIGHEST PERFORMANCE OTDR:. The (MTSe) OTDR module is the fastest and most accurate OTDR to-date. It offers a dynamic range of up to 44 dB at 1550 nm and boasts a 0.1 second sweep time. As part of the (MTSe), the OTDR module has a test capability of more than 200 km and can measure up to 128,000 separate data points with 4 cm sampling resolution. The product’s short dead zone enables the user to differentiate events down to 1 meter. ADVANCED MODULAR TESTER FOR FIBER CHARACTERIZATION: The unique Acterna Media Test Set(MTSe) is a universal fiber test platform with a range of plug-in modules providing a comprehensive, integrated solution for OTDR, DWDM, Chromatic Dispersion and Polarization Mode- Dispersion testing in one field-rugged instrument. Powerful, easy to use and highly cost-effective, (MTSe) is designed to push the boundaries of field test productivity for network installers, operators and maintenance teams.

A wide range of field-interchangeable modules is available for the MTSe platform, including OTDRs for short haul(SR), medium haul(DR), long haul (HD), very long haul(VHD) and 1625nm, WDM modules for C and L-band testing, optical spectrum analyzers, polarization mode dispersion and chromatic dispersion testers, visual fault locators, optical talk sets and a range of light sources and power meters. Acterna’s optical time domain reflectometer(OTDR)and loss test(LTS) plug-in modules are compact, yet powerful additions to the (MTSe) family of testers. The OTDR module is the industry’s fastest,offering the highest performance solutions of any OTDR field instrument on the market. Used with the (MTSe) platform, both the OTDR and LTS modules deliver high accuracy, cost effective, reliable testing for the installation and maintenance of optical fiber networks. HIGHLIGHTS:. New generation singlemode and multimode modules. From LAN (1.5 m event dead zone) to very long haul applications(44 dB dynamic range).

High performance testing (up to 128,000 acquisition points with 0.1 s real time sweep). Fiber characterization using field interchangeable CD, PMD, LTS, OTDR, DWDM testing modules.

Offers maximum portability (3.5 kg) and up to 16 hours battery operation. A complete range of PC software to enhance your OTDR reporting capabilities on (MTSe). OPTIMIZED FUNCTIONS FOR IN-DEPTH ANALYSIS/OPERATION: The OTDR's bidirectional analysis capability enables true splice loss measurement with both end traces. Its multiple trace management feature greatly assists the process of proactively managing fiber problems and helps compare different current and stored measurements for in-depth analysis. A powerful macro-function enables users to perform a series of tests without on going user intervention.

SUITABLE FOR EVERY SKILL LEVEL: Whatever the user’s skill level, the OTDR module and MTSe instrument combination can rise to the challenge. Direct access keys ensure that users can access all the instrument’s sophisticated features via a highly intuitive interface and by a compre- hensive setup and results screen.The OTDR module delivers complete trace analysis, with a direct link between trace and table.

ENHANCED REPORTING POWER: Powerful instruments require powerful reporting tools. The OTDR andloss test set come with the most complete analysis and reporting software. The package supports direct Ethernet transfer to a PC running Acterna’s OFS-100 Optical Fiber Trace Software or OFS-200 Optical Fiber Cable Software. This enables users to perform automatic multiple trace analysis and print out cable test results in batches, for fast generation of dedicated acceptance reports. A MULTITUDE OF TESTING EXCELLENCE MODELS: The (MTSe) houses all the essential tools for installation and maintenance of fiber optic links. The complete range of test modules enables fiber characterization using a single unit. 5026VSR Very Short Range Module Specifications Central wavelength 1310/1550 nm ± 20 nm Laser safety class (21 CFR) Class 1 Pulse width 10 ns to 10 µs Distance range Up to 260 km RMS dynamic range 31 dB/29 dB Event dead zone 3 m Attenuation dead zone 25 m Copyright © 2003-2011 AAATesters.com Phone: 419-517-6681 Toll Free: 1-800-548-2381.

I've checked the application, but the PDF option doesn't exist which means you have to do this in another way. Access the following link to download CutePDF Writer. Install it and make sure you are connected to the Internet since it needs to download some support libraries. Once the app is installed, open the XLS file and go to File Print Setup. Choose the CutePDF Writer from the list and continue with the print procedure.

You will be prompted to save the PDF file. Type a name and that's it.
